Semi-automatic foil application and sealing system

Semi-automatic foil application and sealing system

Semi-automatic foil application and sealing device that is used for sealing a wide variety of plastic and glass containers. The foil application device is positioned on the left side and the sealing device is on the right. Both devices feature step-less manual height adjustment with height scale, heat protection shield, control unit for the regulation of temperature, sealing time and pressure.
See Product Detail

User-friendly conduction sealing devices

Core Specifications

  • Harcor Warranty

Product Details

Features

  • Electro-pneumatic.
  • Heat protection shield.
  • Control unit for the regulation of temperature, sealing time and pressure.
  • Stepless pressure regulation.
  • Manual height adjustment with height scale.

Foil application device features (left hand side)

Vacuum suction nozzle.

Roller guide with running slide.

Foil magazine for stackable pre-cut sealing lids.

Foil dispensing with 2 spot pre-sealing.

Sealing device features (right hand side)

Anodised aluminium sealing head heating block that is swingable.

Removable pre-sealing plates.

Hollowed out sealing die, adaptable to sealing head.

Electrical connections

Power supply: 230 V

Supply frequency: 50/60 Hz

Rated current: 5 A

Power consumption, sealing: 1 KW

Power consumption, foil application: 0,5 KW

Compressed air connection: 2-4 bar

Air consumption: 0,8 m³/h

Sealing parameters

Sealing head heating block (WxDxH): 100 x100 x25 mm
Pre-sealing heating block (WxDxH): 30 x 100 x30 mm
Sealing temperature: 100 – 300 °C
Stroke, sealing unit: 25 mm
Stroke, foil application: 150 mm
Sealing time: 0,5 – 10 s
Sealing capacity: approx. 700 pcs/h
Container size (D/H): maximum 200/220 mm
Variable height adjustment: 0-240 mm

Dimensions and weight

Dimensions (WxDxH): 700 x 620 x 740 mm

Weight: 81 kg
